Patterns

This tutorial looks at how we can create patterns to use for element fills ant outlines.

To apply a pattern to an element, we need to do two things:

• Create a pattern object.
• Assign it to element’s fillPattern and/or strokePattern.

Creating a pattern

Pattern object is created using its new() method:

TypeScript

am5.LinePattern.new(root, {
  color: am5.color(0xffffff),
  rotation: 45,
  width: 200,
  height: 200
});

JavaScript

am5.LinePattern.new(root, {
  color: am5.color(0xffffff),
  rotation: 45,
  width: 200,
  height: 200
});

Basic pattern types

Pattern class	Example
LinePattern
RectanglePattern
CirclePattern
StarPattern
TrianglePattern
PathPattern
GrainPattern

Patterns can be customized by applying rotation, gap, stroke, and other settings, which we’ll explore in a bit.

Setting pattern

To set a pattern fill on an element, we need to assign it to element’s fillPattern setting.

Similarly, to assign it to element’s stroke (line), we can use strokePattern.

TypeScript

columnSeries.columns.template.set("fillPattern", am5.LinePattern.new(root, {
  color: am5.color(0xffffff),
  angle: 45,
  width: 200,
  height: 200
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.LinePattern.new(root, {
  color: am5.color(0xffffff),
  angle: 45,
  width: 200,
  height: 200
}));

Colors

Primary color

To set a color and opacity for pattern shapes, we use its color and colorOpacity settings.

If those are not set, the pattern will inherit stroke and fill colors from the element it is applied to.

TypeScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  color: am5.color(0xffffff),
  colorOpacity: 0.5
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  color: am5.color(0xffffff),
  colorOpacity: 0.5
}));

Fill color

Pattern will use color to color it shapes, but will leave gaps between them transparent.

If we’d rather have that area filled, we can use pattern’s fill and fillOpacity settings.

We can also “invert” the color pattern, by setting fill but omitting the color setting.

TypeScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  fill: am5.color(0xffffff),
  fillOpacity: 1
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  fill: am5.color(0xffffff),
  fillOpacity: 1
}));

Color inheritance

If fill color is not set, pattern will have a transparent background.

In such case, any original fill that target object has - either via its own fill or fillGradient - will be visible through the pattern.

Sizing patterns

Most patterns will try to auto-size themselves to fit the target element.

However, in some cases, you might need to manually size them. In such cases, we can use width and height settings:

TypeScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  color: am5.color(0x297373),
  fill: am5.color(0xffffff),
  rotation: 45,
  width: 400,
  height: 400,
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  color: am5.color(0x297373),
  fill: am5.color(0xffffff),
  rotation: 45,
  width: 400,
  height: 400,
}));

Rotation

By setting rotation on a pattern, we can create wholly distinctive patterns:

TypeScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  fill: am5.color(0xffffff),
  fillOpacity: 1,
  rotation: 45
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  fill: am5.color(0xffffff),
  fillOpacity: 1,
  rotation: 45
}));

Note

Some rotated patterns will tile well. Some tweaking of gap, width, height, and possibly other settings might be required.

Rotating line pattern

A better way to rotate a LinePattern is to use its angle setting (instead of rotation). It’s faster than basic rotation as it will draw lines at specific angle instead of rotating the numerous tiles.

TypeScript

columnSeries.columns.template.set("fillPattern", am5.LinePattern.new(root, {  color: am5.color(0xffffff),  angle: 45,  width: 200,  height: 200}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.LinePattern.new(root, {  color: am5.color(0xffffff),  angle: 45,  width: 200,  height: 200}));

Rotating rectangles

To turn rectangles into diamonds (or place them at any other angle than 0), set its rotateShapes: true in addition to rotation. It will rotate each individual rectangle rather than the whole pattern tile, which is faster.

TypeScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  fill: am5.color(0xffffff),
  fillOpacity: 1,
  rotation: 45,
  rotateShapes: true
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  fill: am5.color(0xffffff),
  fillOpacity: 1,
  rotation: 45,
  rotateShapes: true
}));

Repetition

Normally, pattern repeats the tiles in all directions, until all of the target area is filled.

The setting repetition can be used to change that.

Available values are: "repeat" (default), "repeat-x", "repeat-y", and "no-repeat".

Note

Changing repetition may cause element not fully filled.

Configuration

Each pattern type also has specific configuration settings.

For example, gap setting is available in all pattern types, and is used to set spacing between elements: lines, rectangles, or other shapes.

TypeScript

columnSeries.columns.template.set("fillPattern", am5.LinePattern.new(root, {
  color: am5.color(0xffffff),
  angle: 45,
  width: 200,
  height: 200,
  gap: 10
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.LinePattern.new(root, {
  color: am5.color(0xffffff),
  angle: 45,
  width: 200,
  height: 200,
  gap: 10
}));

There are also type specific settings, e.g. checkered (default: false) for rectangle and circle patterns:

TypeScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  color: am5.color(0xffffff),
  checkered: true
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.RectanglePattern.new(root, {
  color: am5.color(0xffffff),
  checkered: true
}));

For more configuration options, visit following class references:

• LinePattern settings
• RectanglePattern settings
• CirclePattern settings
• PathPattern settings

Examples

The below example uses CirclePattern and LinePattern:

Open in CodePen

And this one uses a PathPattern to use SVG paths as a fill pattern:

Open in CodePen

Image patterns

Creating an image pattern

We can also use any image (external or in-line) as a pattern using PicturePattern.

It requires its setting src to be set either to a URL of the image:

TypeScript

columnSeries.columns.template.set("fillPattern", am5.PicturePattern.new(root, {
  src: "/path/to/pattern.svg"
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.PicturePattern.new(root, {
  src: "/path/to/pattern.svg"
}));

Or it can also contain a data URL (in-line) info:

TypeScript

columnSeries.columns.template.set("fillPattern", am5.PicturePattern.new(root, {
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.PicturePattern.new(root, {
}));

Sizing and fitting

There are a few ways to size the pattern using fit setting, which accepts three values:

• "image" (default) - the pattern will automatically size itself using image’s native dimensions.
• "pattern" - will size image using pattern’s width and height settings.
• "none" - will size pattern tiles according to width and height settings, but will let the image use own dimensions. Using this option is risky since it may produce non-fitting tiles if image is larger than the tile.

The following code will make pattern use custom dimensions, effectively sizing the image:

TypeScript

columnSeries.columns.template.set("fillPattern", am5.PicturePattern.new(root, {
  src: "/path/to/pattern.svg",
  fit: "pattern",
  width: 100,
  height: 100
}));

JavaScript

columnSeries.columns.template.set("fillPattern", am5.PicturePattern.new(root, {
  src: "/path/to/pattern.svg",
  fit: "pattern",
  width: 100,
  height: 100
}));

Here’s an example:

Open in CodePen

Grain patterns

Grain pattern is another special kind of pattern that can complement regular fills with overhead pixel noise to add that additional fuzzy look.

It works by applying a random assortment of semi-transparent dots over existing fills.

Adding grain pattern

As with other patterns, we use fillPattern to add grain pattern:

TypeScript

series.slices.template.setAll({
  fillPattern: am5.GrainPattern.new(root, {})
});

JavaScript

series.slices.template.setAll({
  fillPattern: am5.GrainPattern.new(root, {})
});

Configuring noise pixels

There are a few configuration options we can use to tweak appearance of the noise pixels.

Setting	Value range	Default	Comment
size	1 to X	1	Size of a grain in pixels.
density	0 to 1	1	Density of pixels. The closer number to 1 the more dense the noise. 0 means no noise.
minOpacity	0 to 1	0	Minimum opacity of a noise pixel.
maxOpacity	0 to 1	0.3	Maximum opacity of a noise pixel.
colors	N/A		An array of Color objects to use for noise pixels. Will use color setting or black if colors is not set.
horizontalGap	0 to X		Horizontal gap between noise pixels measured in size.
verticalGap	0 to X		Vertical gap between noise pixels measured in size.

Combining with gradients

We can also combine grain pattern with gradient fills as both fillGradient and fillPattern will be honored:

TypeScript

series.slices.template.setAll({
  fillGradient: am5.RadialGradient.new(root, {
    stops: [
      { offset: 0.5 },
      { brighten: -0.5 }]
  }),
  fillPattern: am5.GrainPattern.new(root, {})
});

JavaScript

series.slices.template.setAll({
  fillGradient: am5.RadialGradient.new(root, {
    stops: [
      { offset: 0.5 },
      { brighten: -0.5 }]
  }),
  fillPattern: am5.GrainPattern.new(root, {})
});

Open in CodePen

Pattern sets

Pattern sets, similar to color sets, are collection patterns that can be used to auto-assign pattern fills to series elements, like slices, series, nodes, etc.

Pattern sets are created by instantiating a PatternSet class. It will have a predefined list of some distinctive patterns, which, upon need, can be overridden (see later in this section).

XY chart

An XYChart can auto-assign fillPattern to each series added to it.

All we need to do is to set patterns setting with a value holding a reference to a PatternSet object:

TypeScript

let chart = root.container.children.push(am5xy.XYChart.new(root, {
  patterns: am5.PatternSet.new(root, {})
}));

JavaScript

var chart = root.container.children.push(am5xy.XYChart.new(root, {
  patterns: am5.PatternSet.new(root, {})
}));

Pie chart

In a PieChart (or any other Percent chart type), instead of chart, we set patterns to its series, because we will need to assign a different pattern to each individual item (slice):

TypeScript

let series = chart.series.push(am5percent.PieSeries.new(root, {
  valueField: "sales",
  categoryField: "country",
  patterns: am5.PatternSet.new(root, {})
}));

JavaScript

var series = chart.series.push(am5percent.PieSeries.new(root, {
  valueField: "sales",
  categoryField: "country",
  patterns: am5.PatternSet.new(root, {})
}));

Hierarchy charts

Similarly, in Hierarchy charts (Force-directed, Treemap), we set patterns directly on series:

TypeScript

let series = container.children.push(
  am5hierarchy.Treemap.new(root, {
    valueField: "value",
    categoryField: "name",
    childDataField: "children",
    patterns: am5.PatternSet.new(root, {})
  })
);

JavaScript

var series = container.children.push(
  am5hierarchy.Treemap.new(root, {
    valueField: "value",
    categoryField: "name",
    childDataField: "children",
    patterns: am5.PatternSet.new(root, {})
  })
);

Flow charts

For a Flow chart (e.g. Sankey, Chord), we assign patterns to its nodes template:

TypeScript

series.nodes.set("patterns", am5.PatternSet.new(root, {}));

JavaScript

series.nodes.set("patterns", am5.PatternSet.new(root, {}));

Customizing colors

The default patterns from the set will use a light interface stroke color for their elements (lines, squares, etc.) and will have no fill, so that original fill of the target element is visible.

If you are using a dark theme, it will use its dark stroke interface color instead.

To override the default element color, we can use pattern set’s color setting:

TypeScript

let series = chart.series.push(am5percent.PieSeries.new(root, {
  valueField: "sales",
  categoryField: "country",
  patterns: am5.PatternSet.new(root, {
    color: am5.color(0x000000)
  })
}));

JavaScript

var series = chart.series.push(am5percent.PieSeries.new(root, {
  valueField: "sales",
  categoryField: "country",
  patterns: am5.PatternSet.new(root, {
    color: am5.color(0x000000)
  })
}));

Custom pattern list

We can also override a default list of patterns with our own, by setting set’s patterns with an array of Pattern objects.

TypeScript

let series = chart.series.push(am5percent.PieSeries.new(root, {
  valueField: "sales",
  categoryField: "country",
  patterns: am5.PatternSet.new(root, {
    patterns: [
      am5.LinePattern.new(root, {
        color: am5.color(0xffffff),
        rotation: 45,
        width: 200,
        height: 200,
        gap: 10
      }),
      am5.RectanglePattern.new(root, {
        color: am5.color(0xffffff),
        checkered: true
      })
    ]
  })
}));

JavaScript

var series = chart.series.push(am5percent.PieSeries.new(root, {
  valueField: "sales",
  categoryField: "country",
  patterns: am5.PatternSet.new(root, {
    patterns: [
      am5.LinePattern.new(root, {
        color: am5.color(0xffffff),
        rotation: 45,
        width: 200,
        height: 200,
        gap: 10
      }),
      am5.RectanglePattern.new(root, {
        color: am5.color(0xffffff),
        checkered: true
      })
    ]
  })
}));

Related tutorials

• Using custom theme to apply patterns to pie chart slices
